S-807 Series

The S-807 Series is an adjustment-free high-precision voltage detector made using the CMOS process.  The output voltage is fixed internally,with an accuracy of ±2.4%.  Two output types are available, Nch open-drain and CMOS output (active "H" and "L"), both of which have various product lineups.  This series features much lower current consumption and higher detection voltage accuracy than the S-805 Series.  Super-miniature package is added for the S-807 Series, the S-807XXSX Series.  This small SOT-23-5 style package allows the designer to shrink the size of his finished product.  Electrical specs for the S-807XXSX Series are the same as the standard S-807 Series.  Output forms of the S-807XXSX Series are Nch open-drain and CMOS active "L".
