General Description
SDA12 General Description
The SDA12 Schottky Barrier Diode Array is designed to reduce reflection noise on high speed parallel data lines.
The device helps suppress transients caused by transmission line reflections, cross talk and switching noise.
The SDA12 consists of an array of 6 high speed Schottky diode pairs suitable for clamping to VCC and / or Gnd.
SDA12 Maximum Ratings
Steady-State Reverse Voltage 7V
Continuous Forward Current 50mA(1)
170mA(2)
Repetitive Peak Forward Current (3) 200mA(1)
1A(2)
Continuous Total Power Dissipation (4) 625mW
(SO or DIL packages)
Operating Free-air Temperature Range 0 to 70°C
Storage Temperature Range -65 to 150°C
* Stresses beyond those listed above may cause permanent damage to the device. These are stress
ratings only and functional operation of the device at these or any other conditions beyond those
indicated under the recommended operating conditions is not implied. Exposure to absolute
maximum rated conditions for extended periods of time may affect device reliability.
Continuous Forward Current 50mA(1)
170mA(2)
Repetitive Peak Forward Current (3) 200mA(1)
1A(2)
Continuous Total Power Dissipation (4) 625mW
(SO or DIL packages)
Operating Free-air Temperature Range 0 to 70°C
Storage Temperature Range -65 to 150°C
* Stresses beyond those listed above may cause permanent damage to the device. These are stress
ratings only and functional operation of the device at these or any other conditions beyond those
indicated under the recommended operating conditions is not implied. Exposure to absolute
maximum rated conditions for extended periods of time may affect device reliability.
SDA12 Features
· Reduced reflection noise
· Repetitive peak forward current - 200mA
· 6 diode pairs
· SO8 and DIL8 packages
· Repetitive peak forward current - 200mA
· 6 diode pairs
· SO8 and DIL8 packages
SDA12 Typical Application
· Termination of data lines
· Protection of memory devices
· Protection of memory devices
SDA12 Connection Diagram
sda12
PDF/DataSheet Download
- Datasheet: sda12
- File Size: 670973 KB
- Manufacturer: ETC [ETC]
- Click here to Download
