SDA 9187-2X
-
Suppliers
DataSheet
General Description
SDA 9187-2X Maximum Ratings
| Parameter | Symbol | Limit Values | Unit | |
| min. | max. | |||
| Supply voltage | VDD VDD A |
0.3 0.3 |
6,5 6,5 |
V V |
| Voltages at I/O pins | VIN | 0.3 | 6,5 | V |
| Voltages differences between VREF H and VREF L | VREF | 4 | 4 | V |
| Ambient temperature | TA | 20 | 70 | °C |
| Storage temperature | Tstg | 20 | 125 | °C |
| Power dissipation | Ptot | 0.8 | W | |
SDA 9187-2X Features
· 3 separate A/D-converters
· Resolution: 6 bit
· Sampling rate: 13.5 MHz, 3.375 MHz
· Clamping circuit for the input signals
· Adjustable delay for the luminance signal (8 steps)
· Color difference signals Y and V can be inverted
· Internal clock synchronization by sandcastle signal
· System clock generation for picture insertion processor
SDA 9187-2X Connection Diagram
