MFG:Texas Instruments Category:Integrated Circuits (ICs)
Category: Integrated Circuits (ICs)
MFG: Texas Instruments
Descriptions: IC PWM CTRLR W/SD 16-SOIC
840
.43400
364.56
| Technical/Catalog Information | SG2524D |
| Vendor | Texas Instruments |
| Category | Integrated Circuits (ICs) |
| PWM Type | Voltage Mode |
| Number of Outputs | 2 |
| Package / Case | 16-SOIC (3.9mm Width) |
| Packaging | Tube |
| Duty Cycle | 45% |
| Voltage - Supply | 8 V ~ 40 V |
| Frequency-Max | 722kHz |
| Buck | Yes |
| Boost | Yes |
| Flyback | Yes |
| Inverting | Yes |
| Doubler | No |
| Divider | No |
| Cuk | No |
| Isolated | No |
| Drawing Number | 296; 4040047-4; D; 16 |
| Operating Temperature | -25°C ~ 85°C |
| Lead Free Status | Lead Free |
| RoHS Status | RoHS Compliant |
| Other Names | SG2524D SG2524D SG2524DTI ND SG2524DTIND SG2524DTI |
SG2524D
PDF/DataSheet Download
IC PWM POWER SUPPLY SW 16DIP
IC PWM POWER SUPPLY SW 16SOIC
The SG2524B is a pulse width modulator for switching power supplies which features improved performance over industry standards like the SG2524B. A direct pin-for-pin replacement for the earlier device, it combines advanced processing techniques and circuit ...
The SG2524, and SG3524 incorporate on a single monolithic chip all the function required for the construction of regulating power suppies inverters or switching regulators. The SG2524can also be used as the control element for high power-output applications....
