SPT7830

• 10-Bit, 1 kHz to 2.5 MSPS Analog-to-Digital Converter
• Monolithic CMOS
• Serial Output
• Internal Sample-and-Hold
• Analog Input Range: 0 to 2 V Nominal; 3.3 V Max
• Power Dissipation (Excluding Reference Ladder)45 mW at +5 V 16 mW at +3.0 V
• Single Power Supply: +3 V to +5 V Range
• High ESD Protection: 3,000 V Minimum

• Handheld and Desktop Scanners
• DSP Interface Applications
• Portable Digital Radios
• Portable and Handheld Applications
• Automotive Applications
• Remote Sensing

The SPT7830 10-bit, 2.5 MSPS, serial analog-to-digital converter  delivers excellent high speed conversion perfor-mance with low cost and low power. The serial port protocols compatible with the serial peripheral interface (SPI) or MICROWIRE™  industry standard, high-speed synchronous
MPU interfaces. The large input bandwidth and fast transient response time allow for CCD applications operating up to 2.5 MSPS.

The device can operate with a power supply range from +3 V to +5 V with very low power dissipation.The small package size makes this part excellent for hand-held appli-cations where board space is at a premium. The SPT7830 is available in an 8-lead SOIC package over the commercial
and industrial temperature ranges. Contact the factory for availability of die.
