IXTV26N50PS, IXTV26N60P, IXTX24N100

Table of contents:
Info of IXTV26N50PS
Info of IXTV26N60P
Info of IXTX24N100

IXTV26N50PS, IXTV26N60P, IXTX24N100 Selling Leads, Datasheet

MFG:IXYS Category:Discrete Semiconductor Products Package Cooled:TO-220 D/C:05+

IXTV26N50PS, IXTV26N60P, IXTX24N100 Datasheet download

Five Points

Part Number: IXTV26N60P

Category: Discrete Semiconductor Products

MFG: IXYS

Package Cooled: TO-220

D/C: 05+

Description: MOSFET N-CH 1000V 24A PLUS247

Price Break

100

Unit Price

3.34950

Extended Price

334.95

(All prices are in USD) Prices for reference only

Attentive hint

Want to post a buying lead? If you are not a member yet, please select the specific/related part number first and then fill the quantity and your contact details in the "Request for Quotation Form" on the left, and then click "Send RFQ".Your buying lead can then be posted, and the reliable suppliers will quote via our online message system or other channels soon.

How to buy ?

How long will receive a response.

Top Sellers:

TOP

IXTV26N50PS Parameters

Technical/Catalog Information	IXTV26N50PS
Vendor	IXYS
Category	Discrete Semiconductor Products
Mounting Type	Surface Mount
FET Polarity	N-Channel
Drain to Source Voltage (Vdss)	500V
Current - Continuous Drain (Id) @ 25° C	26A
Rds On (Max) @ Id, Vgs	230 mOhm @ 500mA, 10V
Input Capacitance (Ciss) @ Vds	3600pF @ 25V
Power - Max	400W
Packaging	Tube
Gate Charge (Qg) @ Vgs	65nC @ 10V
Package / Case	PLUS-220SMD
FET Feature	Standard
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	IXTV26N50PS IXTV26N50PS

IXTV26N60P Parameters

Technical/Catalog Information	IXTV26N60P
Vendor	IXYS
Category	Discrete Semiconductor Products
Mounting Type	Through Hole
FET Polarity	N-Channel
Drain to Source Voltage (Vdss)	600V
Current - Continuous Drain (Id) @ 25° C	26A
Rds On (Max) @ Id, Vgs	270 mOhm @ 500mA, 10V
Input Capacitance (Ciss) @ Vds	4150pF @ 25V
Power - Max	460W
Packaging	Tube
Gate Charge (Qg) @ Vgs	72nC @ 10V
Package / Case	PLUS-220
FET Feature	Standard
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	IXTV26N60P IXTV26N60P

IXTX24N100 Parameters

Technical/Catalog Information	IXTX24N100
Vendor	IXYS
Category	Discrete Semiconductor Products
Mounting Type	Through Hole
FET Polarity	N-Channel
Drain to Source Voltage (Vdss)	1000V (1kV)
Current - Continuous Drain (Id) @ 25° C	24A
Rds On (Max) @ Id, Vgs	400 mOhm @ 500mA, 10V
Input Capacitance (Ciss) @ Vds	8700pF @ 25V
Power - Max	568W
Packaging	Tube
Gate Charge (Qg) @ Vgs	267nC @ 10V
Package / Case	PLUS 247
FET Feature	Standard
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	IXTX24N100 IXTX24N100
