DIFFERENTIAL_TEMPERATURE_SENSOR

Published:2009/7/10 22:40:00 Author:May | From:SeekIC

Respands to difference in temperatures of MTS102 silicon high-precision temperature sensors having range of-40℃ to＋150℃ With both sensors at same temperature,100K pot is adjusted so utputvo voltage is 0.000 V．Opamptypes are not crjtio al R1 is 27K for measurements in Celsius or kelvin and 15K for Fahrenheit measurements.- Silicon Temperature Sensors, Motorola,Phoenix,AZ,1978,DS 2536
