BY329-1700S

Features: * Low forward volt drop* Fast switching* Soft recovery characteristic* High thermal cycling performance* Low thermal resistancePinoutSpecifications SYMBOL PARAMETER CONDITIONS MIN. MAX. UNIT VRSM Peak non-repetitive peakreverse voltage 1500 V VRRM Peak repetitive...

product image

BY329-1700S Picture
See larger image
SeekIC No. : 004305313 Detail

BY329-1700S: Features: * Low forward volt drop* Fast switching* Soft recovery characteristic* High thermal cycling performance* Low thermal resistancePinoutSpecifications SYMBOL PARAMETER CONDITIONS MIN....

BY329-1700S Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
BY329-1700S
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/4/26

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

* Low forward volt drop
* Fast switching
* Soft recovery characteristic
* High thermal cycling performance
* Low thermal resistance


Pinout

Connection Diagram


Specifications

SYMBOL PARAMETER CONDITIONS MIN. MAX. UNIT
VRSM Peak non-repetitive peak
reverse voltage		 1500 V
VRRM Peak repetitive reverse
voltage		 1500 V
VRWM Crest working reverse voltage 1300 V
I F(peak) Peak working forward curren f = 16 kHz
f = 64 kHz		 6
6		 A
I FRM Peak repetitive forward
current		 t = 25 s; = 0.5;
Tmb 123 		14 A
IF(RMS) RMS forward current 11 A
IFSM Peak non-repetitive forward
current		 t = 10 ms
sinusoidal; Tj = 150  prior to
surge; with reapplied V
RWM(max)		 75 A
Tstg storage temperature -40 +150
Tj operating junction temperature +150



Description

Glass-passivated double diffused rectifierdiodefeaturinglowforward voltage drop, fast reverse recovery and soft recovery characteristic. BY329-1700S  is intended for use in TV receivers and PC monitors.

The BY329 series BY329-1700S is supplied in the conventional leaded SOD59 (TO220AC) package.
