FDB44N25 Picture
See larger image
SeekIC No. : 004341040 Detail

FDB44N25: Features: • 44A, 250V, RDS(on) = 0.069Ω @VGS = 10 V• Low gate charge ( typical 47 nC)• Low Crss ( typical 60 pF)• Fast switching• 100% avalanche tested• Imp...

FDB44N25 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
FDB44N25
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/4/15

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

• 44A, 250V, RDS(on) = 0.069Ω @VGS = 10 V
• Low gate charge ( typical 47 nC)
• Low Crss ( typical  60 pF)
• Fast switching
• 100% avalanche tested
• Improved dv/dt capability


Specifications

Symbol
Parameter
FDB44N25
Units
VDSS
Drain-Source Voltage
250
V
ID
Drain Current - Continuous (TC = 25°C)
                      - Continuous (TC  = 100°C)
44
A
26.4
A
IDM
Drain Current - Pulsed                (Note 1)
176
A
VGSS
Gate-Source Voltage
± 30
V
EAS
Single Pulsed Avalanche Energy (Note 2)
2055
mJ
IAR
Avalanche Current                      (Note 1)
44
A
EAR
Repetitive Avalanche Energy      (Note 1)
30.7
mJ
dv/dt
Peak Diode Recovery dv/dt         (Note 3)
4.5
V/ns
PD
Power Dissipation (TC = 25°C)
                             - Derate above 25°C
307
2.45
W
W/°C
TJ, TSTG
Operating and Storage Temperature Range
-55 to +150
°C
TL
Maximum lead temperature for soldering purposes,1/8" from case for 5 seconds
300
°C



Description

These FDB44N25 N-Channel enhancement mode power field effect transistors are produced using Fairchild's proprietary, planar stripe,DMOS technology.

This advanced technology has been especially tailored to minimize on-state resistance, provide superior switching performance, and withstand high energy pulse in the avalanche and commutation mode. These devices FDB44N25 are well suited for high efficient switched mode power supplies and active power factor correction.
