MFG:MDT Package Cooled:DIP D/C:07+
MFG: MDT
Package Cooled: DIP
D/C: 07+
Description: This EPROM-Based 8-bit micro-controller uses a fully static CMOS technology process to achieve higher ...
This EPROM-Based 8-bit micro-controller uses a fully static CMOS technology process to achieve higher speed and smaller size with the low power consumption and high noise immunity. On chip memory includes 4K words of ROM, and 192 bytes of static RAM.
Fully COMS static design
8-bit data bus
On chip EPROM size : 4.0 K words
Internal RAM size : 234 bytes (192 general purpose registers, 42 special registers)
37 single word instructions
14-bit instructions
8-level stacks
Operating voltage : 2.5 V ~ 6.0 V (PRD Disable) 4.5 V ~ 6.0 V (PRD Enable)
Operating frequency : DC ~ 20 MHz
The most fast execution time is 200 ns under 20 MHz in all single cycle instructions except the branch instruction
Addressing modes include direct, indirect and relative addressing modes
Power-on Reset
Power edge-detector Reset
Power range-detector Reset
Sleep Mode for power saving
Capture, Compare, PWM module
Synchronous serial port with SCM
11 interrupt sources:
-External INT pin
-TMR0 timer, TMR1 timer, TMR2 timer
-A/D conversion completion
-Port B<7:4> interrupt on change
-CCP1, CCP2, SCM, USAR, USAT
A/D converter module:
-5 analog inputs multiplexed into one A/D converter
-8-bit resolution
TMR0 : 8-bit real time clock/counter TMR1 : 16-bit real time clock/count TMR2 : 8-bit clock/counter(internal)
4 types of oscillator can be selected by programming option: RC-Low cost RC oscillator LFXT-Low frequency crystal oscillator XTAL-Standard crystal oscillator HFXT-High frequency crystal oscillator
On-chip RC oscillator based Watchdog Timer(WDT)
22 I/O pins with their own independent direction control
The application areas of this MDT10P73 range from appliance motor control and high speed auto-motive to low power remote transmitters/receivers, pointing devices, and telecommunications processors, such as Remote controller, small instruments, chargers, toy, automobile and PC peripheral . etc.
MDT10P73
