- Conforms to POCSAG standard for pagers
- 512, 1200 or 2400 bps signal speed
- Multiframe compatible (each address individually controllable)
- 8 addresses ´ 4 sub-address (total of 32 addresses) control
- Built-in buffer memory
- Supports tone, numeric or character call messages
- Built-in input signal filter, with filter ON/OFF and 4 selectable filter characteristics
- PLL-compatible battery saving method (BS1, BS2, BS3 outputs)
- BS1 (RF control main output signal) 61-step setup time setting
- BS3 (PLL setup signal) 61-step setup time setting
- BS2 (RF DC-level adjustment signal) before/during reception selectable adjustment timing
- 1-bit and 2-bit burst error auto-correction function
- 25 to 75% duty factor signal coverage
- 8 rate error detection condition settings
- 76.8 kHz system clock (crystal oscillator)
- 76.8 or 38.4 kHz clock output pin
- Built-in oscillator capacitor and feedback resistor
- 2.0 to 3.5 V operating supply voltage
- Molybdenum-gate CMOS process realizes low power dissipation
- 16-pin SSOP
Parameter |
Symbol |
Condition |
Rating |
Unit |
Supply voltage range |
VDD |
-0.3 to 7.0 |
V | |
Input voltage range |
VIN |
VSS-0.3 to VDD+0.3 |
V | |
Storage temperature range |
TSTG |
-40 to 125 |
°C | |
Power dissipation |
PW |
250 |
mW | |
Soldering temperature |
TSLD |
255 |
°C | |
Soldering time |
tSLD |
10 |
sec. |
