Purchase SPP73N03S2L-08, In-stock SPP73N03S2L-08 From SeekIC.
MFG:INFINEON Package Cooled:TO-220 D/C:08+
Part Number: SPP73N03S2L-08
MFG: INFINEON
Package Cooled: TO-220
D/C: 08+
- Table of contents:
SPP73N03S2L-08
-
Suppliers
DataSheet
General Description
SPP73N03S2L-08 Maximum Ratings
| Parameter | Symbol | Value | Unit |
| Continuous drain current1) TC = 25 °C |
ID | 73 62 |
A |
| Pulsed drain current TC = 25 °C |
ID puls | 320 | |
| Avalanche energy, single pulse ID =73A, VDD = 25 V, RGS = 25 |
EAS | 170 | mJ |
| Repetitive avalanche energy, limited by Tjmax 2) | EAR | 10 | |
| Reverse diode dv/dt IS =73 A, VDS =24, di/dt = 200 A/s, Tjmax = 175 °C |
dv/dt | 6 | kV/s |
| Gate source voltage | VGS | ±20 | V |
| Power dissipation TC = 25 °C |
Ptot | 107 | W |
| Operating and storage temperature | Tj , Tstg | -55... +175 | °C |
| IEC climatic category; DIN IEC 68-1 | 55/175/56 |
1 Current limited by bondwire ; with an RthJC = 1.4K/W the chip is able to carry ID= 873A at 25°C, for detailed information see app.-note ANPS071E available at www.infineon.com/optimos
2 Defined by design. Not subject to production test
SPP73N03S2L-08 Features
· N-Channel
· Enhancement mode
· Logic Level
· Excellent Gate Charge x RDS(on) product (FOM)
· Superior thermal resistance
· 175°C operating temperature
· Avalanche rated
· dv/dt rated
SPP73N03S2L-08
PDF/DataSheet Download
- Datasheet: SPP73N03S2L-08
- File Size: 425746 KB
- Manufacturer: INFINEON [Infineon Technologies AG]
- Click here to Download
