S1T8527C

• Operating voltage range: 2.0V - 5.5V
• Typical supply current: 13.5mA at 3.6V
• Built-in low battery detection function ( selectable 3.45V, 3.3V, 3.0V, 2.2V, 2.1V )
• Built-in speaker amplifier
• Built-in splatter filter
• Built-in dual conversion receiver, compander and universal PLL
• FM Receiver - Complete dual conversion circuit - Excellent input sensitivity (0.7mVrms at 12dB SINAD)
• Compader - Easy gain control to use external component - Included ALC (Automatic Level Control) circuit - Included Mute logic
• Universal PLL - RX (TX) divided counter range: 1/16 - 1/16383 - Reference frequency divided counter range: 1/16 - 1/4095 - Lock detector signal output - Serial interface with MCU for controlling each block

S1T8527C is a monolithic circuit which can be used in high performance 60MHz MCA type CLP System. The S1T8527C is a subsystem IC for FM / FSK receiving systems and a complete one chip FM / FSK receiver IC for 60MHz system. It's feature includes receiving functions for FM / FSK systems, a compander to remove external noise, and PLL ( Phase Lock Loop ) of channel selection which blocks surrounding frequency interference. The S1T8527C can be used with a wide range of FM / FSK VHF bandwidth systems, including cordless phone, and the narrow band voice and data sending / receiving systems. To make applications easily and simply, peripheral parts are minimized.
