MFG:LINFINIT Package Cooled:DIP
MFG: LINFINIT
Package Cooled: DIP
Description: The SG2524, and SG3524 incorporate on a single monolithic chip all the function required for the const...
The SG2524, and SG3524 incorporate on a single monolithic chip all the function required for the construction of regulating power suppies inverters or switching regulators. They can also be used as the control element for high power-output applications. The SG3524 family was designed for switching regulators of either polarity, transformer- coupled dc-to-dc converters, transformerless voltage doublers and polarity converter applications employing fixed-frequency, pulse-width modulation techniques. The dual alternating outputs allows either single-ended or push-pull applications.Each device includes an on-ship reference, error amplifier, programmable oscillator, steering flip flop, two uncommitted output transistors, a high-gain comparator, and currentlimiting and shut-down circuitry.
|
Parameter |
Symbol |
Value |
Unit |
|
Supply Voltage |
VIN |
40 |
V |
|
Reference Output Current |
IC |
100 |
mA |
|
Current Through CT Terminal |
IR |
50 |
mA |
|
Total Power Dissipation at Tamb = 70°C |
IT |
5 |
mA |
|
1000 |
mw | ||
|
Storage Temperature Range |
Tstg |
65 to 150 |
°C |
|
Collector Output Current |
IC |
65 to 150 |
°C |
|
Operating Ambient Temperature Range: SG2524 SG3524 |
Top |
25 to 850 to 70 |
°C |
SG2524
PDF/DataSheet Download
